TDM LCD TP AD Board

All Check

SIZE：

ALL 2 2.4 2.5 2.8 3.5 4.3 5 5.7 6.50 6.86 7 8 8.4 10.1 10.4 10.5 11.6 12.1 12.2 13.3 15 15.6 17 18.5 19 21.5 21.6 23.8 24 27 31.6 32 43 49 55 65

RATIO：

ALL 240*320 320*240 375*812 480*272 480*800 480*1280 640*480 800x480 800*600 1024*600 1024*768 1280*800 1280*1024 1366*768 1920*1080 1920x1080 @60Hz 3840*2160 4K2K @60Hz -

RANKING TYPE

Size	AF Model No.	Actuation area	Active Area	Brightness (Nits)	Life Time	CR	Interface	Viewing Angle	OT	Module Size	Touch Controller	Bonding
7.00	AF070G1024600H300SA-0	155.30*86.60	1024*600	300	20K	800	USB/VGA/HDMI	75/75/70/70	0 ~ +50 ℃	186.18*119.90	Iitek/COF	Tape bonding
10.10	AF101G1280800U500SA-1	216.90*135.60	1280*800	500	50K	800	USB/VGA/HDMI	89/89/89/89	-20 ~+70 ℃	176.00*260.00	Iitek/COB	Tape bonding
10.10	AF101G1280800H350SA-0	216.90*135.60	1280*800	350	30K	800	USB/VGA/HDMI	85/85/85/85	0 ~ +50 ℃	260.00*178.00	Iitek/COB	Tape bonding
12.10	AF121G1024768U500SA-1	246.00*185.00	1024*768	500	50K	700	USB/VGA/HDMI	80/80/70/70	-30 ~+85 ℃	298.00*232.70	Iitek/COB	Tape bonding
12.10	AF121G1024768H350SA-0	246.00*185.00	1024*768	350	30K	800	USB/VGA/HDMI	80/80/80/80	0 ~ +50 ℃	298.00*232.70	Iitek/COB	Tape bonding
15.00	AF150G1024768U400SA-1	304.00*228.00	1024*768	400	50K	1000	USB/VGA/HDMI	89/89/89/89	-20 ~+70 ℃	351.10*275.10	Iitek/COB	Tape bonding
15.00	AF150G1024768H300SA-0	304.00*228.00	1024*768	300	70K	2000	USB/VGA/HDMI	88/88/88/88	0 ~ +50 ℃	351.10*275.10	Iitek/COB	Tape bonding
15.60	AF156G1366768U400SA-1	344.00*193.00	1366*768	400	50K	800	USB/VGA/DVI	85/85/50/80	-30 ~+85 ℃	386.67*235.98	Iitek/COB	Tape bonding
15.60	AF156G19201080D250SA-0	344.00*193.00	1920*1080	250	30K	800	USB/VGA/DVI	89/89/89/89	0 ~ +50 ℃	386.67*235.98	Iitek/COB	Tape bonding
17.00	AF170G12801024U350SA-1	337.90*270.30	1280*1024	350	50K	800	USB/VGA/HDMI	80/80/60/80	-30 ~+85 ℃	380.00*312.00	Iitek/COB	Tape bonding
